Melia LED ME2

ME2
G431-LED
A high-performance wall-mount luminaire available in brass or powder-coated housing
Configure this product

Product Overview

Designed and constructed for performance, the Wall Mount G431-LED Melia provides diffuse illumination in either a brass or powder-coated aluminum housing. This luminaire features new Lumascape d5 driver technology for advanced dimming and control options.

Features

Lumen Output 220lm Power Consumption 3.5W Control Protocol PWM (0-10V, DMX) IP Rating IP65 Compliance CE RCM Colour Options Cool White Warm White Blue Download Datasheet

Downloads

Install Guide Download Datasheet
G431-LED - IES Files.zip ZIP (19.05 KB)

Related

Technology

Product Configurator

G431-LED _ _ _ _ _
Login to view pricing
Reset to Default Clear Selected Add

Customise Melia LED ME2 below

Light Engine

Required

3W (3)

Light Source

Required

3,000K, 80 CRI (H6)

3,000K, 80 CRI (H6)

Warm White (80 CRI, 3 SDCM)

2,700K, 80 CRI (D7)

2,700K, 80 CRI (D7)

Warm White (80 CRI, 3 SDCM)

4,000K, 80 CRI (W4)

4,000K, 80 CRI (W4)

Cool White (80 CRI, 3 SDCM)

470nm (B4)

470nm (B4)

Blue

Beam Angles

Published angles may vary slightly to photo-metric data. Please refer to IES files where relevant.

Required

Narrow (NR)

Narrow (NR)

14°

Narrow Medium (NM)

Narrow Medium (NM)

25°

Medium (ME)

Medium (ME)

30°

Wide (WD)

Wide (WD)

40º

Input Voltage

GardenQ

Required

24V DC - Dimmable (D)

24V DC - Dimmable (D)

PWM Dimmable Driver, 24V DC

Finish

Custom powder coat colours are available. Please consult factory.

Required

Polished Brass (PB)

Polished Brass (PB)

Polished Brass finish

Black (BL)

Black (BL)

RAL9004 from RAL Classic collection (formerly CB)

More info
Anthracite Grey (AG)

Anthracite Grey (AG)

RAL7016 from RAL Classic collection

More info
Basalt Grey (BT)

Basalt Grey (BT)

RAL7012 from RAL Classic collection

More info
Anodic Silver (SL)

Anodic Silver (SL)

RAL9006 from RAL Classic collection (formerly CS)

More info
White (WT)

White (WT)

RAL9016 from RAL Classic collection

More info
Dark Bronze (DB)

Dark Bronze (DB)

RAL8019 from RAL Classic collection

More info
Latte (LT)

Latte (LT)

RAL7006 from RAL Classic collection

More info
Dark Aluminium (DA)

Dark Aluminium (DA)

RAL9007 from RAL Classic collection

More info
Custom RAL (CC)

Custom RAL (CC)

Custom Colour Accessory required. MOQ applies. Consult Lumascape for pricing

More info

Accessories

Accessories

Copper Hood (LS603-CU)

Polished copper hood for G431-LED

Hood (G603-*)

Order to Match Luminaire Powder Coat Colour
